Description
The KCE® silicon carbide grinding barrels/linings/liners/cylinders are formed by cold isostatic pressing and is produced through reaction sintering or pressureless sintering. Inner edge manufacturing, outer diameter and end face precision machining can be carried out according to design requirements to meet different design needs of users. The silicon carbide grinding barrels/linings/liners/cylinders are customized according to customer drawings.
Specifications
KCE® SiSiC/RBSiC/SSiC Technical Data Sheet
| Technical Parameters | Unit | SiSiC/RBSiC Value | SSiC Value |
| Silicon Carbide content | % | 85 | 99 |
| Free Silicon content | % | 15 | 0 |
| Bulk Density 20°C | g/cm³ | ≥3.02 | ≥3.10 |
| Open Porosity | Vol % | 0 | 0 |
| Hardness HK | kg/mm² | 2600 | 2800 |
| Flexural Strength 20°C | MPa | 250 | 380 |
| Flexural Strength 1200°C | MPa | 280 | 400 |
| 20 – 1000°C (Coefficient of Thermal Expansion) | 10–6 K–1 | 4.5 | 4.1 |
| Thermal Conductivity 1000°C | W/m.K | 45 | 74 |
| Static 20°C（Modulus of Elasticity ) | GPa | 330 | 420 |
| Working temperature | °C | 1300 | 1600 |
| Max. Service Temp (air) | °C | 1380 | 1680 |
Applications
They can be used as conveying pipelines or grinding machine liners for strong corrosion, particle erosion, and high temperature conditions, and are applied in industries such as inkjet, fine chemical, pharmaceutical, medical, semiconductor material grinding, lithium battery cathode material (such as LiCoO ₂) grinding, high-purity ceramic powder grinding, etc.
Advantages
The KCE® Silicon carbide grinding bucket is a type of silicon carbide ceramic product, which has extremely low wear and chemical corrosion resistance, can prevent material pollution, and has extremely high grinding efficiency. It is suitable for various grinding and dispersion occasions, with a long service life (5-10 times that of general wear-resistant materials) and low overall operating costs. It has high hardness, strength, wear resistance, high temperature resistance, good thermal conductivity, and low overall usage cost.
Compared with common zirconia ceramic grinding cylinders, the application of silicon carbide in sand mill grinding cylinders has several advantages such as fast heat dissipation, low cost, and greater wear resistance. The advantage of fast heat dissipation can prevent material agglomeration in the grinding body due to high temperature, thereby improving grinding efficiency.
